QC3.0 12V 24V to 5V 3A 3.2A

Product Name

Car Charger Quick Charge 3.0 12V 24V to 5V 3.2A

Brand

HYCO

Model No.

Module Properties

non-isolated buck module

Rectification

synchronous rectification

Input

Input Voltage

DC 12V 24V

Input Voltage Range

DC 12-36V

Output

Output Voltage

DC 3.7V-12V Adaptive

Output Current

3.2A

Output Power

20W

 Conversion Efficiency

Voltage regulation

±1%

Load regulation

± 2%

Ripple (Full load test)

< 150mV

No-load current

<100mA

Working Temperature

-40~80℃

Waterproof Rating

IP67

Protection

Over-current protection

Over-voltage protection

Overheat protection

Short-circuit protection

Reverse Polarity Protection

Application

Certification

CE/RoHS/FCC

  Case Material

Plastic, anti-shock, anti-drop, anti-moisture, anti-dust and so on

  Product Size (L x W x H)

46*32*18mm

Product Weight

120g

Warranty

12 months, lifetime up to 100,000 hours

Cooling Way

Free air convection

OEM&ODM Service
